Measures PM2.5, PM10, CO2, Temperature & Humidity. Airveda monitors use High quality laser sensors, calibrated individually for Indian conditions against BAM (Beta Attenuation Monitor- the most advanced system for measuring ambient air quality.) This device contains high quality NDIR CO2 sensor, which allows user to easily self-calibrate ensuring best results. Temp and humidity sensors are calibrated by a master source traceable to NABL.
The small size and long battery life of 14-16 hours makes Airveda monitors extremely portable. Can be charged using any USB power outlet in your car, laptop or power bank. The monitor measures your air quality every second so you can understand the air quality where you are, in real-time.
Airveda monitors are completely manufactured in India. Sensors are also calibrated locally to suit Indian conditions. Sensors can be locally re-calibrated as well as replaced easily. Our manufacturing facility has been running for 30 years and is a trusted name in the local industry.
Connect to your home, office or personal hotspot Wi-Fi and remotely monitor data and get alerts in Airveda app, available for free on iOS and Android. View current and historic data, understand your exposure over time, as well as compare with outdoor air quality in your city.
The monitor stores data locally if no Wi-Fi is available. Data is uploaded to server when Wi-Fi becomes available. By reducing the frequency of measurement you can increase the number of days for which the data will be stored.
The default life of PM sensors is 1 year. However, a special feature allows the sensor to switch on/off at regular intervals to increase the life of the sensor considerably. This interval is configurable and can be configured to once every minute, 5 minutes, 10 minutes and 20 minutes.
₹ 23999 (inclusive of all taxes) ₹ 26000
PRODUCT DETAILS
Technical Specifications
-
Measurement
- Measurement parameters: PM2.5, PM10, CO2, Temp, Humidity
- PM
- Range of PM2.5: 0-999 μg/m3
- Range of PM10: 0-1999 μg/m3
- Minimum resolution of < 0.3 μm
- Relative error Maximum of ±10% and ±10μg/m3
- Response time: Less than 10 seconds when scene changes
- CO2
- Range: 0 to 5000ppm
- Accuracy: 50ppm +-3%
- Response time: 2 minutes
- Self calibrating. Can be manually calibrated by taking device outdoors and long pressing Setup Button.
- Temperature
- Range: 10 to 60 degrees C
- Accuracy: 1 deg C
- Resolution: 1 deg C
- Humidity
- Range: 0 to 90% RH
- Accuracy: 3%
- Resolution: 1%
-
Portable
- Size: 11.6cm*11.6cm*6cm
- Power voltage: 5V
- Can be charged via laptop/car USB
- Weight: 370 gms
- 2*2900 mAh re-chargeable battery with 14-16 hours of battery backup
Warranty & Support
- 1 Year warranty against any manufacturing defects.
- Client responsible for getting device to our facilities for all servicing. Service time 1 week.
- Warranty is void if device is opened, tampered with or electronics damaged due to mechanical shock.
- Sensor change and calibration is not included in warranty.
Working Principle
- PM sensor uses laser scattering principle: Light scattering can be induced when particles go through the detecting area. The scattered light is transformed into electrical signals and these signals will be amplified and processed. The number and diameter of particles can be obtained by analysis because the signal waveform has certain relations with the particles diameter.
- CO2 sensor is dual wavelength NDIR based (Nondispersive infrared sensor).
- Temperature sensor is CMOS, Humidity is Capacitive.
Tested and calibrated against
- PM: Beta Attenuation Monitor (BAM)
- CO2: Can be self-calibrated to 400ppm outdoors by taking monitor outdoors and long pressing Setup button on monitor.
- Temp & Humidity calibrated with a master traceable to NABL.
Wifi Connectivity
- Connects to wifi. Data available in Android and iOS apps along with Indian AQI, day, week, month history as well as outdoor data in different parts of the city.
